System Design at Scale: How to Design a URL Shortener That Handles 100 Million Requests Per Day

Whether you're building for 100 users or 100 million, the decisions you make about data storage, caching, and service decomposition determine whether your system will survive under load. The URL shortener is the perfect teaching vehicle: simple enough to reason about in an interview, complex enough to surface every major system design challenge.

Before drawing any diagrams, clarify requirements:

• Given a long URL, generate a unique short URL (e.g., bit.ly/abc123)
• Given a short URL, redirect to the original long URL
• Custom aliases (optional): user can choose their slug
• Link expiration: links expire after a configurable TTL (default: 5 years)
• Analytics: track click count per short URL

• 100 million reads/day (1,157 redirects/second average, ~10,000/second peak)
• 10 million writes/day (new short URLs created)
• 99.99% availability — 52 minutes of downtime/year maximum
• Sub-100ms redirect latency at the 99th percentile
• Durability: short URLs must never silently disappear

Back-of-envelope math drives architecture decisions:

Read:Write ratio = 10:1
Writes: 10M/day = 115 writes/second
Reads:  100M/day = 1,157 reads/second (~10K peak)

Storage:
  Average URL: 200 bytes
  Writes/day: 10M × 200B = 2GB/day
  5-year retention: 2GB × 365 × 5 = 3.6TB total URL storage

Bandwidth:
  Write: 115 RPS × 200B = 23KB/s (trivial)
  Read: 1,157 RPS × 500B (response) = 578KB/s average

Key insight: reads dominate by 10:1. The entire architecture should optimize for read performance.

The core challenge: given any long URL, generate a unique 7-character short code.

MD5("https://bipinbaral.com.np/blog/system-design")
= "a9f3d2c1e84b72...56af"

Take first 7 chars = "a9f3d2c"

Problem: Collision rate with 7 chars is 1 / 62^7 = 1 in 3.5 trillion. Sounds safe, but with 10M URLs/day, collisions become statistically significant after ~1 billion URLs.

Use a globally unique counter. Encode the counter in Base62 (a-zA-Z0-9):

Counter: 1,000,000,000 → Base62 → "15ftgG"
Counter: 1,000,000,001 → Base62 → "15ftgH"

Guarantees uniqueness. Predictable. Fast to generate.

Problem: If using a single counter, it's a single point of failure and a write bottleneck.

Use multiple counter ranges assigned to app server "ranges":

Server A: gets IDs 1,000,000 → 2,000,000
Server B: gets IDs 2,000,000 → 3,000,000
Server C: gets IDs 3,000,000 → 4,000,000

Each server assigns IDs within its range without coordination. When a server exhausts its range, it requests a new one from the Counter Service (ZooKeeper or a dedicated microservice).

CREATE TABLE urls (
  id          BIGSERIAL PRIMARY KEY,
  short_code  VARCHAR(8)   NOT NULL UNIQUE,
  long_url    TEXT         NOT NULL,
  user_id     UUID         REFERENCES users(id),
  custom_alias BOOLEAN     DEFAULT FALSE,
  expires_at  TIMESTAMPTZ,
  created_at  TIMESTAMPTZ  DEFAULT NOW(),
  click_count BIGINT       DEFAULT 0
);

CREATE INDEX idx_urls_short_code ON urls (short_code);
CREATE INDEX idx_urls_expires_at ON urls (expires_at)
  WHERE expires_at IS NOT NULL;

At 3.6TB over 5 years, a single PostgreSQL instance can handle this comfortably. But if we project to 1 billion URLs/day, we need horizontal sharding.

Shard by the first character of short_code:

• Shard 0: a-g (7 chars = ~11% of keyspace)
• Shard 1: h-n
• Shard 2: o-u
• Shard 3: v-z + 0-9

Each shard is an independent PostgreSQL cluster with a primary and two read replicas.

Given our 10:1 read/write ratio, caching is the most important performance lever.

┌─────────────────────────────────────────────┐
│                   Client                    │
└─────────────────┬───────────────────────────┘
                  │ GET /abc123
┌─────────────────▼───────────────────────────┐
│              Load Balancer                  │
└─────────────────┬───────────────────────────┘
                  │
┌─────────────────▼───────────────────────────┐
│         Redirect Service (Node.js)          │
│  1. Check Redis cache for "abc123"          │
│  2. HIT → return 301 redirect               │
│  3. MISS → query DB, populate cache, return │
└─────────────────┬───────────────────────────┘
                  │
         ┌────────▼────────┐
         │   Redis Cluster │  TTL: 24 hours
         │  (6 nodes, HA)  │  ~50M entries in memory
         └────────▲────────┘
                  │ on cache miss
         ┌────────▼────────┐
         │  PostgreSQL DB  │
         │  (primary +     │
         │   read replicas)│
         └─────────────────┘

Key:   "url:abc123"
Value: "https://www.example.com/very/long/path?with=params"
TTL:   86400 (24 hours) — refreshed on hit

With 16GB Redis memory and an average URL of 200 bytes:

16GB / 200B = 80 million URLs cached — covering our top 80% of traffic (hot URLs).

This is a critical decision with significant performance implications:

Recommendation: Use 302 if you need click analytics. Use 301 only for static redirects you'll never change.

                    DNS
                     │
            ┌────────▼────────┐
            │   Cloudflare    │  ← Global CDN + DDoS protection
            └────────┬────────┘
                     │
         ┌───────────▼───────────┐
         │    AWS ALB            │  ← Multi-AZ load balancer
         └───┬─────────────┬─────┘
             │             │
    ┌────────▼──┐    ┌──▼────────┐
    │  App Server│   │  App Server│  ← Auto-scaling group
    │  (us-east) │   │  (us-west) │    Min: 3 instances
    └────────────┘   └────────────┘    Max: 50 instances

Multi-region active-active: Write operations go to the nearest region. Read operations served from local Redis cache in each region. Database replication (async) keeps all regions synced within ~100ms.

Click tracking at 1,157 RPS can't write directly to PostgreSQL per click (it becomes a write bottleneck). Instead:

Click event → Kafka topic ("url-clicks") → Kafka Consumer → Batch aggregate → PostgreSQL counter update every 60 seconds

This decouples analytics from the critical redirect path.

Designing a URL shortener exposes every major system design challenge: hash function design, database sharding, cache invalidation, distributed counters, analytics pipelines, and geographic distribution. The key insight is that reads always dominate — optimize every layer for read throughput, and writes will take care of themselves at this scale.
